SCOPREGA TURBO MAX 12 V Bedienungsanleitung Seite 12

POWER CABLE
2.
The cable section must match the length of the on-board system:
·
For cable length up to 6 m: 10 mm section
·
For cable length from 6 m to 12 m: 16 mm section
3. FIXATION DU GONFLEUR
The inflator can be mounted on the dinghy by means of the supplied "B" brackets.
Otherwise, it can be wall-mounted after cutting a hole (pic. 6), by securing it to the "A" holes
through Ø 4,5 mm self-threading screws. Maximum screw length inside the inflator: 8 mm.
5
4. INFLATION TUBE ASSEMBLY
Cut the hose to the needed length. Insert the large red connector into one of the hose ends to
connect it to the inflator. Glue the soft PVC adaptor onto the other end of the hose, then
insert the correct inflation valve fitting, which keeps the valve open.
2
2
Instructions manual
Rev. 01-2020
