Electrical connection

The installed electric motor is completely wired ready tor operation.
The customer's connection to the power supply system, and any extension
cables that may be used, must conform with local regulations.
Important remark:
The motor is automatical/y switched off in the event of an overload. The
motor can be switched on again after a cooling down period that can
vary.
Defective electrical connection cables
Electrical connection cables offen suffer insulation darnage.
Possible causes are:
• Punch points when connection cables are run through window or door gaps.
• Kinks resulting from incorrect attachment or laying of the connection cable.
• Cuts resulting from running over the connecting cable.
• Insulation darnage resulting from forcefully pulling out of the wall socket.
• Cracks through aging of insulation.
Such defective electrical connection cables must not be used as
the insulation darnage makes them extremely hazardous.
Check electrical connection cables regularly for darnage. Make sure
the cable is disconnected from the mains when checking.
Electrical connection cables must comply with the regulations applica-
ble in your country .

Single-phase motor

• The mains voltage must coincide with the voltage specified on the motor.s
rating plate.
• Dimension cables up to a length of 25
m must have a cross-section of 1.5
mm♠. and beyond 25 m at least 2.5
mm♠.
• The connection to the mains must be protected with a 16 A slowacting fuse.

Three-phase motor

• The mains voltage must be between 380 and 420 V / 50 Hz.
• The connection to the mains and the connection cable must have
five leads (3 P + N + PE).
• Extension cables must have a cross-section of at least 1.5 mm2.
Warning:
The drill press must not be operated in the open air. The machine must have an
earth Gable to protect the operator from etectrical shocks.
Accessories and Attachments
Warning
Use only accessories designed for this drill press to avoid injury from thrown
broken parts or workpieces.
Do not use any accessory unless you have completely read the instruction or
owner's manual for that accessory
Carton Contents
Unpacking and checking contents
Warning
If any part is missing or damaged, do not plug the drill press in until the missing or
damaged part is replaced, and assembly is complete. Carefully unpack the drill
press and all its parts, and compare against the illustration below.
To protect the drill press from moisture, a protective coating has been applied to
the machined surfaces. Remove this coating with a soft
cloth and WD-40.
&
Warning
To avoid fire or toxic reaction, never use gasoline, naphtha, acetone, lacquer
thinner or similar high I y volatile solvents to clean the drill press.
Save these instructions
7
.
