POS. BENENNUNG
KÜHLKREIS FK71 50/60HZ
1
DRUCK GEHÄUSE FK71
2
MANTEL RT FK71
3
VENTILATOR M.F. 220V42W 150x55
4
NETZK. PVC ÖY 5X0,75 1,45M
5
WASSERKÜHLER
6
KLEMMLEISTE 2,5 12 16 1EFDS
7
SCHNELLKUPPLUNG AG R1/8" NW5
8
WASSERANSCHL. SW
VST357/457
9
MUTTER KST ROT VST357/457
10
MUTTER KST SW
VST 357/457
11
ABDECKKAPPE 11.0/13.5/10.3/3.2
12
KLEMME 1OHR 16.6 STUFENLOS
13
ZUGENTLASTUNG PVC 7.1-9 3
14
PUMPE Y2841.0023 M.YDS3-MOTOR
15
TANKDECKEL FK2600
16
WASSERBEHÄLTER FK 71
17
SCHLAUCH RAUFI MG 8x3 TR
18
WINKELSTÜCK KST. D=10,0/7,0x31
19
SCHLAUCH PVC OG 10X2 TR
FK 71
Ersatzteilliste / Spare parts list / Listes de pièces de rechange / Lista de repuestos / Lista de pecas sobresselentes / Lista dei Ricambi
1
5
13
4
7-10
17
ARTICLE
FK 71 50/60HZ COOLING UNIT
CASE FK71
SHEATH FK71
FAN MOTOR 220V42W 150X55
MAIN CABLE PVC 5X0.75 1.45M FK
WATER COOLER
TERMINAL STRIP 2.5MM2/EKL 1
QUICK CONNECT AG R1/8" NW5
WATER-CONNECT BLUE VST357/457
NUT KST RED VST357/457
NUT KST BLUE VST 357/457
COVER-DISC 11.0/13.5/10.3/3.2
CLAMPING 1 CLIP 16.6
TRACTION RELEASE D=7.1-9/3MM
PUMP Y2841.0023 M.YDS3-M
COVER FK2600
WATERTANK FK71
RAUFILAM HOSE MG 8X3 TR
ANGLE ADAPTER KST D=10.0/70X31
PVC HOSE 10x2 TR
2
18
3
16
11
6
14
DENOMINATION
REFROIDISSEUR FK 71 50/60HZ
COUVERCLE FK71
CHEMISE FK71
MOTEUR VENTILATEUR 220V42W 150
CABLE DE DISTRIBOUTION 5X0.75
REFRIGERATEUR A L.EAU
BORNIER BK 2,5MM2/EKL 1
RACCORD RAPIDE AG R1/8" NW5
CONNECTION EAU BLEU VST357/457
ECROU ROUGE VST357/457
ECROU BLEU VST357/457
COUVERCLE 11.0/13.5/10.3/3.2
PINCE 1OREILLE 16.6
ECROU DE FREIN 7,1/9 3 MM
POMPE Y2841.0023 M.YDS3-M
TANK CAP FK2600
RESERVOIR D.EAU FK71
TUYAU RAUFILAM MG 8X3 TR
RACCORD ANGULAIRE D=10,0/7x31
TUYAU PVC 10x2 TR
19
12
15
AM2,0200,8776
el_fr_st_kg_00045
4,045,802
46,0450,0208
43,0006,0039
43,0004,1509
24,0450,0972
41,0009,0060
44,0001,1145
42,0405,0189
42,0405,0186
42,0405,0187
42,0300,1724
42,0407,0442
42,0407,0011
43,0006,0172
42,0401,0865
32,0300,2312
40,0001,0008
42,0300,2019
40,0001,0393
1/1
012001
