Information about the Network Connection

Configuring the PBX using a PC is done using the configuration manager integrated in the
PBX. This can be accessed via the IP address of the PBX. The IP address to be used
depends on your connection and network environment.
•
If the PBX is not connected to a router but is connected directly to a single PC which
receives its IP address automatically (default setting on Windows and Mac OS X), you
can access the PBX via the permanent IP address 169.254.1.240 from the APIPA
address range.
• If the PBX is connected to a router that works as a DHCP server and allocates IP
addresses to the devices connected (default setting on most routers), you can access
the PBX via two IP addresses:
1. Via the permanent IP address 169.254.1.240 from the APIPA address range.
2. Via the IP address allocated by the DHCP server.
Note: If the permanent IP address from the APIPA address range is not working, you
will first have to learn the IP address allocated by the DHCP server. You have the
following options:
• If the UPnP service is installed and activated on the PC (e. g. on Windows 8), the
PBX can be found and selected in the network environment as "COMpact 4000"
device.
• You can use a network scanner (f. e. Angry IP Scanner).
• You can connect a CLIP-capable analogue telephone and query the IP address by
entering the character string ##8*941# and then hanging up the receiver.
Important: If you wish to operate the PBX in a network where IP addresses are
allocated permanently, you must first connect a CLIP-capable analogue telephone
and adapt the IP configuration of the PBX for operation in the network (see next
chapter).
Configuring a Permanent IP Address in the PBX
1. Pick up the receiver of an internal telephone.
2. In sequence, dial ##8, the 6-digit admin PIN (none in the factory settings) and *930*0#.
You will hear the confirmation tone (pulsating tone).
The DHCP client function is disabled in the PBX.
3. Hang up the receiver and then pick it up again.
In sequence, dial ##8, the 6-digit admin PIN (none in the factory settings), *931*, the
4.
12-digit IP address (e. g. for 192.168.2.10: 192168002010) and #.
You will hear the confirmation tone (pulsating tone).
The entered IP address has been configured in the PBX (for subnet mask
255.255.255.0).
5. Hang up the receiver.
