Technical Information - Handicare SystemRoMedic MiniLift125 Gebrauchsanweisung

Technical Information

Lifting speed
Batteries
Charger
Motor (mast)
Motor (base)
Sound level
Material
Emergency lowering
Castors
Weight
Weight loose parts (Foot plate)
Footplate, measurement
Number of lifts per charge
IP class
Expected lifetime
Operating forces buttons on
hand control
Max. load
Medical Device Class I. The product complies with the requirements of the Medical Devices Directive 93/42/EEC.
SystemRoMedic
Downloaded from www.Manualslib.com
35 mm/s without load.
Two 12V, 2.9 Ah valve-regulated, sealed, lead accumulator (gel-type batteries)
Max. 400mA
DC 24 V, 10.5 Ah. Operating time: 10% maximum continuous operation for 2 minutes
Push: 7500N.
DC 24 V, 12.3 Ah. Operating time: 10% maximum continuous operation for 2 minutes
Push: 2000N.
55.8 dB(A)
Steel
Manual and electrical
Front 3,1", 80 mm, back 3,1", 80 mm
39 kg/104,5 lbs
5 kg / 11 lbs
390 x 345 mm / 15.3 x 13.5
20-25
IP X4
10 years
4 N
125 kg/ 275 lbs
