5.3.3 Replacing the Filter Element

Disconnect the motor from the mains and secure it against re-connection.
Let the device cool down.
Relieve the pressure.
Unscrew the filter bowl turning it counter-clockwise. Clean the bowl using in a suitable cleaning
solvent like pure benzine or kerosene.
Remove filter element with a side-to-side motion.
Check O-ring and back-up ring on the filter bowl for damage and replace the gaskets if necessary.
Make sure that the part number on the spare element corresponds with the part number of the filter
label.
Open the plastic bag and push element over the retainer in the filter head.
Now remove the plastic bag.
Complete installation by screwing on the bowl, turning clockwise until it comes to a full stop. Back
off the bowl 1/8 to 1 /2 turn.
Dispose the worn filter element according to local regulations.

6 Service and Disposal

6.1 Service

If the device shows irregularities see chapter 7 for troubleshooting.
If you need help or more information
call +49(0)2102-498955 or your local agent.
Please hold the data of the type plate ready.
If the device doesn't work correctly after elimination of failures and turning power on, the device must be
checked by the manufacturer. Please ship the device with suitable packing to
Bühler Technologies GmbH
- Service -
Halskestr. 23
40880 Ratingen
Germany
Please indicate type of cooler and the serial number and give a short description of the failure as well.

6.2 Disposal

Regard the local regulations for disposal of electric and electronic equipment (motor and temperature
contact) as well as for contaminated filter elements and oil.
