20 Specifications

20 Specifications
20.1 STIHL RMA 2.2 RPV, RMA 2.2 RV Lawn
Mower
– Permissible battery: STIHL AP
– Weight without battery:
– RMA 2.2 RPV: 22.6 kg
– RMA 2.2 RV: 22.4 kg
– Cutting width: 46 cm
– Speed: 3,150 rpm
– Speed in ECO mode: 2,800 rpm
– Minimum driving speed: 2.0 km/h
– Maximum driving speed (depending on the battery used):
– AP 100: 3.0 km/h
– AP 200: 3.7 km/h
– AP 300: 4.5 km/h
For information on the battery life see
www.stihl.com/battery-life.

20.2 Blade

0478-131-9950-A
– Minimum thickness a: 2 mm
– Minimum width b: 45 mm
– Sharpening angle c: 30°

20.3 STIHL AP battery

– Battery Technology: Lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
– Energy content in Wh: see rating label
– Weight in kg: see rating label
– Permissible temperature range for operation and storage:
-10°C to +50°C

20.4 Sound Values and Vibration Values

The K value for the sound pressure level is 2 dB(A). The K
value for the sound power level is 2.4 dB(A). The K value for
the vibration values is 0.7 m/s².
– Sound pressure level L
pA
EN 60335-2-77: 74 dB(A)
– Sound power level L
wA
2000/14/EC: 86 dB(A)
– Vibration value a measured in accordance with EN
hv
60335-2-77, handlebar: 1.4 m/s²
The indicated vibration values have been measured in
accordance with a standardised test method and can be
used for the purpose of comparing electrical appliances. The
actual vibration values that occur may deviate from the
indicated values, depending on the type of application. The
indicated vibration values can be used for an initial
assessment of the vibration load. The actual vibration load
must be assessed. Times during which the electrical
appliance is switched off, along with times in which it is
switched on but running without load, can also be taken into
consideration.
For information on compliance with Employers' Vibration
Directive 2002/44/EC see www.stihl.com/vib.
measured in accordance with
measured in accordance with
