OPERATING MODE

In general, all basic functions of the 2GO! and Digivoice systems are available. Additional functions and
differences are illustrated below.
CALLS
• Only one call at a time is possible on Digivoice side. After the 40s busy time, all communications (including
ones between a 2GO! secondary unit and an apartment stations) can be interrupted by a call in the
concerned column.
• A sandglass will appear on the apartment station monitor in the event of a call from a Digivoice door phone
unit or Digivoice switchboard without additional camera.
CALLS TO SWITCHBOARD
There are two options, according to whether the apartment station column making the call is busy or not.
• Column is not engaged by a communication to an apartment station or is engaged in a communication to a
door unit for longer than 30s. The apartment station monitor making the call will light up and the sandglass
will appear. Column communications where applicable are interrupted.
If the switchboard operator does not reply after 20 seconds, the monitor will switch to standby and the call
will be stored. Hang up and wait for the switchboard operator to call back.
If the switchboard operator replies, the sandglass will remain on the monitor unless the switchboard has a
camera (in which case the camera image will appear).
• The column is engaged by a communication to a door unit for less than 30s: the apartment station monitor
will not light up. The request will be directed to the switchboard where it is stored. The communication in
progress is not interrupted. Hang up and wait for the switchboard operator to call back.
DIGIVOICE MAIN DOOR UNIT NUMBER 980 AUTO POWER-ON
There are two options according to whether the door unit is busy or not.
• Door unit idle. The apartment station monitor making the call will light up and the door unit camera image
will appear.
• Door unit engaged in a communication. The apartment station monitor will light up and the sandglass will
appear. The monitor will go out after a few seconds. The communication in progress will be continued. Try
again later.
SURVEILLANCE CAMERA AUTO-ON FUNCTION
Up to 4 surveillance cameras can be connected to the main calling station number 980. After auto power-on
of station 980, press to cyclically select the surveillance cameras.
SPECIAL DECODER 1038/80 CONTROL
The 2GO! riser users can control the appropriate programmed Digivoice special decoders using the following
buttons:
• Switchboard call button
• Staircase lights button (the staircase light command is converted into a Digivoice special code)
INTERCOM FUNCTION
The intercom function is possible within the 2GO! riser only and not between users on different risers.
20
Downloaded from www.Manualslib.com manuals search engine
DEFAULT CONFIGURATION
The default settings of the gateway are:
column code: 1
main camera distance dip switch: 0-200m.

TROUBLESHOOTING

The yellow LED on the gateway has a similar function to that of the 2GO! apartment station and indicates
anomalies to the 2GO! spine.
Yellow LED on: system fault on 2GO! side. Check the LEDs of all other 2GO! devices in the spine and cut
off, if necessary.
The red LED on the gateway is used for troubleshooting on Digivoice side.
Red LED on: no gateway data connection on Digivoice side. Red LED one blink: Digivoice data transmission
or reception.

TECHNICAL SPECIFICATIONS

Working temperature range:
Draw on Digivoice side:
R1 - R2 terminal draw: 100mA max
DS1082-010 DS1082-010
-5 +45°C
1CU.
