TX-UMTS
EN
Quick-Start Guide
TX-UMTS – Extension module
For Your Safety
Intended use
The extension module TX-UMTS is a wireless modem plug in for the HMIs of
the TX700 series and enables the TX7... to communicate via the internet with
machines and systems worldwide. The extension module provides four LED
indicators for module and network status and a microSIM slot.
The devices may only be used as described in these instructions.
Any other use is not in accordance with the intended use. Turck accepts no li-
ability for any resulting damage.
General safety instructions
■
The device may only be assembled, installed, operated, parameterized and
maintained by professionally-trained personnel.
■
The device only meets the EMC requirements for industrial areas and is not
suitable for use in residential areas.
■
The device may only be used in accordance with applicable national and
international regulations, standards and laws.
■
Only operate the devices in areas where the operation of wireless equipment
is allowed.
■
Any extended stay within the area the UMTS antenna may be harmful to
health. Maintain radiation limits and minimum distances when selecting the
installation location for the antenna.
■
The radiation UMTS antenna may impair the operation of medical equip-
ment. Maintain an additional distance from active radiation sources up to the
maximum transmission distance.
■
When installing the antenna outside: Observe lightning protection e.g. ac-
cording to EN 62305.
■
Switch off the device when working on the antenna.
Product Description
Device overview
See fig. 1
Connectors and slots
See fig. 1
Connector/slot
Function
1
Antenna (included in the scope of delivery)
2
LED displays 1...4
3
I/O channels
4
SIM card slot
5
Expansion slot for plug-in modules
The I/O channels are SELV (Safety Extra - Low Voltage) according to European
standards.
Mounting
WARNING
Influences on lightning protection zone concept
Personal injury and material damage due to lightning strikes
When installing the antenna outside: Observe lightning protection e.g.
➤
according to EN 62305.
Do not override lightning protection zone concept by the antenna and its
➤
feed line.
Remove the protective cover before installation, mount the module as shown
➤
in fig. 2 and connect the supplied antenna (see fig. 1).
ATTENTION
Risk of short circuits
Destruction of electronics!
Do not connect or disconnect teh device when energized.
➤
WARNING
Influences of radio signals on the body
Personal injury due to radio signals
Observe minimum distances to persons according to the following table.
➤
Standard radio signal
EGSM900
DCS1800
WCDMA band I
WCDMA band VIII
GSM 850/900 24
GSM 1800/1900
Connection
See fig. 3
DANGER
Effect on electrically controlled medical devices such as pacemakers
Danger to life due to malfunction or failure of medical equipment
Maintain an additional distance from active radiation sources up to the
➤
maximum transmission distance.
Power supply
The device is supplied via the plug in connection at the TX700.
Digital sensors and actuators
Connect sensors and actuators according to the following pin assignment
➤
using the supplied plug connector.
Pin
Signal
1
OUT 1A
2
OUT 1B
3
OUT 2A
4
OUT 2B
Operating
LED description
See fig. 4
LED
Description
1
Configurable
2
Configurable
3
Modem status ON/OFF
4
Netlight (network status LED)
Maintenance
The devices must be cleaned at regular intervals with a damp cloth.
➤
Repair
The device must not be repaired by the user. The device must be decommis-
sioned if it is faulty. Refer to our return acceptance conditions when returning
the device to Turck.
Disposal
The device must be disposed of correctly and must not be included in
normal household garbage.
© Hans Turck GmbH & Co. KG | 100009981 2020-03 DE EN FR
Minimum distance from the body
13.5 cm
9 cm
5.5 cm
8 cm
24 cm
12 cm
Pin
Signal
5
IN 1+
6
IN 1-
7
IN 2+
8
IN 2-
