Fitting left:
Mount Rearset to Frame
with spacers and M8x40
After adjusting the
shift lever position,
tighten the locknuts
Screw into original uniball joint of gearbox shift
lever.(Use Threadlocker )
Mount the brake pump with the original
screws on the brake pump holder
Mount footpeg with M5x25
and close it with the plastic
cap.
If the brake light switch is not
activated, use a washer to bring
the trigger forward.
———————————————————
Rev. 00 26/04/2017
Mount the original heel
guard with spacers and
M6x18.
Zubehör von
Mount the original heel
guard with spacers and
M6x18.
(Smaller spacer above)
Mount footpeg with M5x25 and close
it with the plastic cap.
Mount Rearset with M8x55 /
M8x30 and spacers to the Frame
Mount OEM Spring.
—
Das Original
——
Seite 5 von 8
