7.2 Parallel stop
The parallel stop (7) has to be used when making
longitudinal cuts in wooden workpieces.
7.2.1 Stop height (Fig. 2a, 10, 11)
•
F it the parallel stop (7) to the saw table (1)
using the clamping plate (26), washers (27)
and locking screws (12): On the outside on
the saw table: locking screw (12) and washer
(27). On the inside of the table: clamping
plate (26).
•
T he parallel stop (7) supplied with the
benchtype circular saw has two different
guide faces.
•
U se the lower stop height for thin
workpieces and the higher stop height for
thick workpieces.
•
T o change the stop height, undo the locking
screws (12) on the parallel stop (7) and take
it off the table.
•
T urn the parallel stop (7) through 180° so
that the end which was facing the front now
faces the rear.
•
T ighten the locking screws (12) again.
7.2.2 Cutting width (Fig. 10, 11)
•
T he parallel stop (7) can be mounted on
either side of the saw table (1).
•
U ndo the two locking screws (12).
•
T he parallel stop (7) can be set to the
required dimension with the help of the scale
(22) engraved on the saw table (1).
•
T ighten the two locking screws (12) in order
to fix the parallel stop (7).
•
M easure the cutting width between the saw
blade and the parallel stop in addition to the
scale indicator. After every new adjustment,
make a trial cut in order to check the set
dimensions.
7.3 Cross stop (Fig. 12) The cross stop (14) has
to be used when making cross cuts in wooden
workpieces.
•
F asten the stop rail (23) using the screws
(24) and the knurled screws (25) on the
cross stop (14).
•
S lide the cross stop (14) into the slot (21) of
the saw table.
•
U ndo the locking screw (28).
•
T urn the stop rail (23) until the arrow points
to the angle required.
Anl_TC_TS_200_SPK9.indb 27
GB
•
R e-tighten the fastening screw (28).
•
C heck the gap between the stop rail (23)
and the saw blade (4).
•
W arning! Do not push the stop rail (23) too
far toward the blade. The distance between
the stop rail (23) and the blade (4) should be
approx. 2 cm.
•
I f necessary, slacken the two knurled
screws
(25) and adjust the stop rail (23).
•
R etighten the knurled screws (25). 7.4
Setting the angle (Fig. 13)
- 23 -
•
S lacken the locking grip (8) at the front and
the locking grip (9) at the rear of the
machine.
•
T o adjust the angle of the saw blade, push
the two locking grips (8, 9) until the pointer
(13) is aligned with the desired angular
setting on the angle scale (10).
•
L ock the locking grips (8, 9).
8. Operation
Warning!
•
A fter every new adjustment we recommend
you to make a trial cut in order to check the
new settings.
•
A fter switching on the saw, wait for the
blade to reach its maximum speed of rotation
before commencing with the cut.
•
T ake extra care when starting the cut!
•
N ever use the equipment without the suction
function.
•
R egularly check and clean the suction
channels.
8.1 Making longitudinal cuts (Fig. 14)
Longitudinal cutting (also known as slitting) is
when you use the saw to cut along the grain of
the wood.
Press one edge of the workpiece against the
parallel stop (7) while the fl at side lies on the
saw table (1).
The blade guard (2) must always be lowered
over the workpiece.
When you make a longitudinal cut, never adopt
a working position that is in line with the cutting
direction.
•
S et the parallel stop (7) in accordance with
the workpiece height and the desired width.
