2. Layout and items supplied

2.1 Layout (Fig. 1-15)
1. Saw table
2. Saw blade guard
3. Push stick
4. Blade
5. Splitter
6. Table insert
7. Complete parallel stop
8. Locking grip for saw blade angle (front)
9. Locking grip for saw blade angle (rear)
10. Angle scale
11. On/Off switch
12. Locking screw for parallel stop
13. Pointer (saw blade angle)
14. Cross stop
15. Screw for saw blade
16. Extractor adapter
17. Countersunk head screw
18. L-shaped recess in the splitter
19. Fastening screw
20. Hole in the machine frame
21. Slot in saw table
22. Scale (cutting width)
23. Stop rail for cross stop
24. Screw for cross stop
25. Knurled screw for cross stop
26. Clamping plate
27. Washer
28. Locking screw for cross stop
29. 19/8 mm ring wrench
30. 10/8 mm ring wrench
31. Saw blade cover
32. Recessed head screw for saw blade cover
33. Rotary knob on saw blade guard
34. Self-locking nut on saw blade guard
35. Lock bolt on saw blade guard
36. Wing nut
2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
Anl_TC_TS_200_SPK9.indb 23
GB
the service information at the end of the
operating instructions.
•
O pen the packaging and take out the
equipment with care.
•
R emove the packaging material and any
packaging and/or transportation braces (if
available).
•
C heck to see if all items are supplied.
•
I nspect the equipment and accessories for
transport damage.
•
I f possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger
of swallowing or suff ocating!
•
Bench-type circular saw
•
Push stick
•
Complete parallel stop
•
C omplete cross stop
•
E xtractor adapter
•
1 9/8 mm ring wrench
•
1 0/8 mm ring wrench
•
W ing nut
•
A ssembly material
•
O riginal operating instructions
•
S afety information
- 20 -

3. Proper use

The bench-type circular saw is designed for the
slitting and cross-cutting (only with the cross
stop) of all types of timber commensurate with
the machine's size. The equipment is not to be
used for cutting any type of round wood.
The equipment is to be used only for its
prescribed purpose. Any other use is deemed to
be a case of misuse. The user / operator and not
the manufacturer will be liable for any damage or
injuries of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the machine is used in commercial,
trade or industrial businesses or for equivalent
purposes.
The equipment is to be operated only with
suitable saw blades (saw blades made of HM or
13.11.2019 12:55:57
