Powerpeak FET8324P Gebrauchsanweisung Seite 31

Step 10: assembling the covers
Attach the covers (38L/R) on the moving handles with four screws (39) and a screw (40). Attach the
front cover plates (45L/R) to the pedal tubes with a screw (46) and a screw (99). Attach the rear cover
plates (51L/R + 52L/R) on the pedal tubes with two screws (99) and a screw (112).
Step 11
When the installation is complete, carefully check and ensure all the screws and nuts are fastened firmly.
Step 12: assembling the adaptor
The adaptor must be connected to the back of the device.
31
