2. Package Contents and Technical Specifications

Remote Control

2
3
4
Dust Bin
1
2
3
1. Dust Bin Handle
2. Dust Bin Lock
3. Filter Net
Downloaded from www.Manualslib.com manuals search engine
8
1. Pause Button
5
2. AUTO Mode Button
1
3. Spot Cleaning Mode Button
4. Edge Cleaning Mode Button
5. Direction Control Buttons
6. Intensive Cleaning Mode Button
6
7. Return to Charger Mode Button
7
8. Infrared Emitter
4. Sponge Filter
5. High Efficiency Filter
6. Dust Bin Cover
4
5
6
7
