6. Einbau mit Dreipunktgurt:
6.1 Heben Sie die Stofflasche (1) an, drücken Sie die
Verriegelungstaste (2) und klappen Sie das Sitzoberteil
nach vorne.
6. Installing with a three-point belt:
6.1 First, lengthen the belts by pressing the central
adjuster, keep it depressed and pull the shoulder
straps (see item 7). Lift the fabric tab (1), press the
locking button (2)
and fold the back of the seat forwards.
6.2 Führen Sie den Dreipunktgurt unterhalb der Schul-
tergurte durch. Achten Sie darauf, dass der Diagnal-
gurt in der dafür vorgesehenen Position liegt.
6.2 Guide the three-point belt through the seat
beneath the shoulder straps and engage the seat
belt buckle. Ensure that the diagonal belt is in the
correct position as shown in diagram 6.2
6.3 Straffen Sie den Beckengurt (1) und den Diagonal-
gurt (2).
6.3 Tighten the lap section (1) and diagonal belt (2).
