Teaching-In - HomeMatic HM-CC-SCD Bedienungsanleitung

6.3
In order to enable communication between radio components,
the devices have to be taught-in to one another. To execute the
teach-in procedure, both of the devices to be linked must be in
teach-in mode.
To teach-in, proceed as follows:
• Press and hold down the channel button on the
radio-controlled sensor for carbon dioxide for at least 4
seconds. The device LED will flash orange for a few seconds.
The teach-in procedure can be aborted by pressing the
teach-in button again briefly (the device LED will then turn red).
• The device to be taught-in then also needs to be switched
to teach-in mode. If both devices are in teach-in mode at the
same time, each will be taught-in to the other.
• Once the teach-in procedure has been completed successfully
for the radio-controlled sensor for carbon dioxide, the device
LED will flash green. How long the LED flashes for depends
upon the configuration progress. If the teach-in attempt has
failed, the device LED will flash red.
• If no teaching-in is carried out, teach-in mode will be exited
automatically after 20 seconds.
teach-in mode as described above, but the device LED will light
up red for two seconds when a button is pressed. Direct teach-in
is not possible. To teach-in the radio-controlled sensor for
carbon dioxide to another central control unit/HomeMatic
component, reset it to the initial state. The WebUI must be used
for teaching-in to a central control unit.
18
Downloaded from www.Manualslib.com

Teaching-in

Please read this entire section before starting the
teach-in procedure.
If the radio-controlled sensor for carbon dioxide has
already been taught-in to a central control unit and is
thus blocked for direct teach-in, it can still be put into
