RouterNode 2, GatewayNode 2,
SmartBridge
Connection
O3
O2
O1.NC
O1.NO
O1.COM

4.1 IO connector

EN
The IO connector enables you to communicate with
external devices. Use a screwdriver to push the spring-
loaded terminal downwards to connect or disconnect
cables. Details and application examples for wiring the
IO-Connector can be found in the RouterNode-2
manual.
Meaning
Open drain output (for details, see
IO connector [ 33]
}
nical specifications [
Open drain output (for details, see
IO connector [ 33]
}
nical specifications [
Potential-free relay output: Nor-
mally Closed (NC). This output is
electrically connected to output
01.COM in the idle state.
Potential-free relay output: Nor-
mally Open (NO). This output is
electrically connected to output
01.COM when energised.
Potential-free relay output: Com-
mon (COM). This output is either
connected to output 01.NC or
01.NO, depending on the switching
state of the relay.
4. Connections
Tech-
und
42]
).
}
Tech-
und
42] ).
}
