Part Names
04
Part Names
Plasma Display
Front view
1
1 POWER button
2 STANDBY indicator
Rear view
5
6
5 SPEAKER (right/left) terminals
6 SYSTEM CABLE terminal (BLACK)
12
En
2
3
3 POWER ON indicator
4 Remote control sensor
SYSTEM
CABLE
WHITE
BLACK
SYSTEM
CABLE
WHITE
BLACK
7 SYSTEM CABLE terminal (WHITE)
8 AC IN terminal
4
7
8
