Power
Indicator on Meaning
Mower
Mower is working
Shining green
properly
Handle-Locking
Clamp/Quick-Ad-
Flashing green
just Lever is not
triggered properly
The battery is
Flashing red
depleted
Shining The mower is
orange overheated
Flashing The mower is
orange overloaded
Red and
Communication
green flashing
timeout
alternately
MOWER OVERLOAD PROTECTION
To prevent overload conditions, do not try to remove too
much grass at one time. Slow down your cutting pace or
raise the cut height.
Your mower has built-in overload circuit protection. When
the mower is overloaded, the motor will stop and the
power indicator on the mower will flash orange. Remove
the battery pack from the mower. Check to see if grass
has collected beneath the deck and clear it if necessary,
then install the battery and restart the mower.
BATTERY HIGH TEMPERATURE PROTECTION
The heat dissipates more slowly in hot weather. If the
battery temperature exceeds 70°C during operation, the
protection circuit will immediately turn off the mower to
protect the battery pack from damage. The power indicator
on the mower will shine orange and the LED on the battery
will flash orange. Release the bail handle, wait until the
battery pack cools down to approximately 67°C, then
restart the mower.
MAINTENANCE
Action
remove the safety key from the mower before cleaning,
N/A
performing any maintenance or transporting the mower.
Re-triggered the
handle-locking
replacement parts. Use of any other parts may create
clamp/quick-adjust
a hazard or cause product damage. To ensure safety
Lever
and reliability, all repairs and replacements should be
Stop the mower and
performed by a qualified service technician.
charge the battery
pack

GENERAL MAINTENANCE

Remove the battery
from the mower,
battery pack when servicing or transporting the mower.
move them to the
shade and cool
The underside of mower deck should be cleaned after each
them at least 15
use, as grass clippings, leaves, dirt and other debris will
minutes
accumulate.
Slow down your
Remove any build-up of grass on or around the drive shaft
pace or raise up
and the motor fan (do not use water). Wipe the mower
the cut height to clean with a damp cloth.
decrease the load
REMOVING/INSTALLING THE BLADE
Connect EGO
heavy gloves or wrapping the cutting edges with rags
or other materials when performing any maintenance
on the mower blade. Always remove the battery pack
when servicing or transporting the mower.
◾
To Remove the Blade
Following Fig. R1.
NOTICE: If the bolt rotates with the motor shaft when
loosening the bolt, turn the fan by hand to align the
through holes in the fan with the holes in the blade, and
place another metal rod into the aligned holes (Fig. R2).
◾
To Install the Blade
Following the assembly sequence in Fig. S, with the
fan blade towards deck and the printed blade side
towards outside, align the through holes in the fan
with the holes in the blade (Fig. T) and then tighten the
blade as Fig. U shown.
Fig. R2 & S parts description see below:
NOTICE: The recommended torque for tightening
the blade bolt is 49-59Nm.
56 VOLT LITHIUM-ION CORDLESS MOWER — LM1900E-SP
WARNING: To avoid serious personal injury, always
WARNING: When servicing, use only identical
WARNING: Always remove the safety key and
WARNING: Always protect your hands by wearing
R2-1 Stabilizer 1 S-2
R2-2 Stabilizer 2 S-3
R2-3 14mm Wrench S-4
S-1 Fan S-5
EN
Inner Flange
Blade
Outer Flange
Bolt
15
