EN
WARNING:
The blade will continue to rotate for
a few seconds after the mower is turned off. Allow the
motor/blade to stop rotating before starting it again. Do
not rapidly turn the mower off and on.
DANGER:
Rotating blades can cause serious injury.
To prevent serious injury, remove the safety key when
the mower is unattended, or when adjusting, cleaning,
servicing, transporting, lifting, or storing the mower.
NOTICE:
The motor cannot be started unless:
◾
The handle is locked into one of the three operating
positions, see ADJUSTING THE FOLDABLE HANDLE.
◾
The side rails are fully extended (Fig. K).
◾
Both green handle-locking clamps are securely closed
(Fig. L).
CAUTION:
Do not attempt to override the operation of
the safety button and bail switch.
To Start (Fig. M1 & M2)
NOTICE:
To prevent serious injury, we recommend you to
start the mower with self-propel function off.
START THE MOWER WITH SELF-PROPEL FUCTION
ON (Fig. M1)
1) Attach the battery pack to the mower, insert the safety
key into the key slot and close the battery cover.
2) According to Fig. M1, depress the one of self-propel
switch.
3) Turn the self-propel Speed-control knob until you
hear a "click".
4) depress the safety button down.
5) With the self-propel and safety button switch
depressed, then pull the bail switch upward to meet
the handle and release the safety button.
START THE MOWER WITH SELF-PROPEL FUCTION
OFF (Fig. M2)
1) Attach the battery pack to the mower, insert the
safety key into the key slot and close the battery
cover.
2) According to Fig. M2, depress the safety button
down.
3) With the safety button depressed, pull the bail switch
upward to meet the handle and release the safety
button.
14
56 VOLT LITHIUM-ION CORDLESS MOWER — LM1900E-SP
To Stop (Fig. N)
1) Fully release the bail switch.
2) The electric brake in the Automatic Braking
Mechanism will stop the blade rotation within 3
seconds of the bail switch release.
3) Turn the self-propel Speed-control knob off until it
can't be rotated.
VARIABLE-SPEED SELF-PROPEL SYSTEM
The mower is equipped with variable-speed self-propel
capability. This system is independent of the blade On-Off
switch. it is not dependent on blade rotation.
To operate the system without blade rotation (Fig. O1)
1) Press the one of self-propel switches.
2) Turn the self-propel Speed-control knob until you
hear a "click".
To turn the self-propel off, release the self-propel switch
and Turn the self-propel Speed-control knob off until it can't
be rotated. (Fig. O2)
WARNING:
To reduce the risk of injury, never attempt
to override the operation of the switch or self-propel
system. Use the self-propel for its intended purpose only.
LED HEADLIGHTS (Fig. A-9)
Press the switch button 1s(Fig. C-23) to turn on/off the LED
headlights in the front of the battery compartment.
FULL-GRASS INDICATOR (Fig. P1 & P2)
THE GRASS BAG IS NOT FULL (Fig. P1).
THE GRASS BAG IS FULL (Fig. P2).
and remove the battery pack, clean your grass bag.
POWER INDICATOR ON THE MOWER (Fig. Q)
The mower is equipped with a power indicator to indicate
the charge status of the battery pack and the working
status of the mower. The power indicator will illuminate
when the blade is rotating or when the LED headlights are
turned on.
Fig. Q parts description see below:
Q-1 Power indicator
Stop the mower
