VARIABLE-SPEED SELF-PROPEL SYSTEM
EN
(only for model LM1700E -SP )
LM1700E-SP mower is equipped with variable-speed self-
propel capability. This system is independent of the blade
On-Off switch. it is not dependent on blade rotation.
To operate the system without blade rotation (Fig. O1)
1) Press the one of self-propel switches.
2) Turn the self-propel Speed-control knob until you
hear a "click".
To turn the self-propel off, release the self-propel switch
and Turn the self-propel Speed-control knob off until it can't
be rotated. (Fig. O2)
WARNING:
To reduce the risk of injury, never attempt
to override the operation of the switch or self-propel
system. Use the self-propel for its intended purpose only.
LED HEADLIGHTS (Fig. A-12)
Press the switch button 1S (Fig. C-26) to turn on/off the LED
headlights in the front of the battery compartment.
FULL-GRASS INDICATOR (Fig. P1 & P2)
THE GRASS BAG IS NOT FULL (Fig. P1).
THE GRASS BAG IS FULL (Fig. P2). Stop the mower and
remove the battery pack, clean your grass bag.
POWER INDICATOR ON THE MOWER (Fig. Q)
The mower is equipped with a power indicator to indicate
the charge status of the battery pack and the working
status of the mower. The power indicator will illuminate
when the blade is rotating or when the LED headlights are
turned on.
Fig. Q parts description see below:
Q-1 Power indicator
Power
Indicator
Meaning
on
Mower
Mower is working
Shining
properly
green
Handle-Locking
Clamp/Quick-
Flashing
Adjust Lever is not
green
triggered properly
Flashing The battery is
red depleted
16
56 VOLT LITHIUM-ION CORDLESS MOWER — LM1700E/LM1700E-SP
MOWER OVERLOAD PROTECTION
To prevent overload conditions, do not try to remove too
much grass at one time. Slow down your cutting pace or
raise the cut height.
Your mower has built-in overload circuit protection. When
the mower is overloaded, the motor will stop and the
power indicator on the mower will flash orange. Remove
the battery pack from the mower. Check to see if grass
has collected beneath the deck and clear it if necessary,
then install the battery and restart the mower.
BATTERY HIGH TEMPERATURE PROTECTION
The heat dissipates more slowly in hot weather. If the
battery temperature exceeds 70°C during operation, the
protection circuit will immediately turn off the mower to
protect the battery pack from damage. The power indicator
on the mower will shine orange and the LED on the battery
will flash orange. Release the bail handle, wait until the
battery pack cools down to approximately 67°C, then
restart the mower.
MAINTENANCE
remove the safety key from the mower before cleaning,
Action
performing any maintenance or transporting the mower.
replacement parts. Use of any other parts may create a
N/A
hazard or cause product damage. To ensure safety and
reliability, all repairs and replacements should be performed
Re-triggered the
by a qualified service technician.
handle-locking clamp/
quick-adjust Lever

GENERAL MAINTENANCE

Stop the mower and
charge the battery
pack when servicing or transporting the mower.
pack
The underside of mower deck should be cleaned after each
use, as grass clippings, leaves, dirt and other debris will
accumulate.
Solid The mower is
orange overheated
Flashing The mower is
orange overloaded
Red and
green
Communication
flashing
timeout
alternately
WARNING:
To avoid serious personal injury, always
WARNING:
When servicing, use only identical
WARNING:
Always remove the safety key and battery
Remove the battery
from the mower, move
them to the shade and
cool them at least 15
minutes
Slow down your pace
or raise up the cut
height to decrease
the load
Connect EGO
