NOTICE:
Under normal usage, bag material is subject to
wear. To reduce the risk of injury, frequently inspect the
bag assembly and replace if there are any signs of wear
or deterioration. Use only grass bags manufactured for
this mower.
ADJUSTING THE FOLDABLE HANDLE
WARNING: Do not attempt to start the mower until
the handle has been locked at one of the three preset
operating positions (UPPER OPERATING POSITION,
MIDDLE OPERATING POSITION and LOWER OPERATING
POSITION).
Your mower is shipped with the handle in the compact,
LOCKED STORAGE POSITION (Fig. F).
1) Press and hold the quick-adjust lever to release the
handle from the LOCKED STORAGE POSITION.
2) Lift the handle from its folded position, then release
the lever. Gently pivot the handle upward until you hear
and feel the lock pin engage in one of the following
different positions as shown in the Fig. G.
Fig. G parts description see below:
G-1 Locked Storage
Position
G-2 Grass Bag
Attachment/Re-
moval Position
G-3 Upper Operating
Position
ATTACHING THE GRASS BAG/MULCHING INSERT
WARNING: Do not at any time make any
adjustment to the lawn mower without first stopping
the motor, removing the safety key and waiting for the
blade to stop rotating.
NOTICE: Attach any of the attachments to the lawn
mower before mowing.
◾
To Attach/Remove the Grass Bag (Fig. H1 & H2)
Insert the board of the grass bag into the mower and
hang the grass bag on the mower.
NOTICE: Remove the pre-installed mulching insert
from the mower before attaching the grass bag to the
mower.
◾
To Attach/Remove the Mulching Insert (Fig. I)
Lift the rear-discharge door and insert the mulching
insert into the mower. To remove, just pull it out. Lastly,
release the rear-discharge door.
G-4 Middle Operating
Position
G-5 Lower Operating
Position
G-6 Cutting Height
Adjusting Level
56 VOLT LITHIUM-ION CORDLESS MOWER — LM1900E-SP
ADJUSTING THE CUTTING HEIGHT (Fig. G)
WARNING:
Keep your feet away from the
deck when adjusting its height. The mower can be set to
20
7 cutting heights between
proper cutting height according to the types and conditions
of the grass.
NOTICE: When moving the tool, make sure the cutting
height is adjusted at the position of 3 or higher. Failure
to do so, could result in the damage of the blade.
ATTACHING/DETACHING THE BATTERY PACK (Fig. J)
CHARGE BEFORE FIRST USE.
WARNING: If any parts are broken or missing, do
not attempt to attach the battery pack to the mower or
operate the mower until the broken or missing parts
are replaced. Failure to do so could result in serious
injury.
◾
To Attach
Push the battery pack into the battery compartment until
you hear a "click".
◾
To Detach
Depress the battery-release button in the battery
compartment.
Fig. J parts description see below:
J-1 Safety Key
J-2 Safety Key Slot
J-3 Battery-release Button
NOTICE:
Make sure that the latch on the mower snaps
into place and that the battery pack is secured to the
mower before starting operation.
STARTING/STOPPING THE MOWER
WARNING:
The operation of any lawn mower
can result in foreign objects being thrown into your or
other's eyes, which can damage eyes severely. Always
wear safety glasses while operating the mower, or while
performing any adjustments or repairs on it.
WARNING:
Ensure that other people and pets
remain at least 30m away from the mower when it is in
use.
mm and 80mm. Choose the
