Technical Specifications; Channel Amplifier - EMPHASER EA2160 Einbau & Bedienungsanleitung

6. teCHnICal speCIFICatIons/teCHnIsCHe spezIFIKatIonen
EA2160

2-CHannel aMplIFIer

150W x 2 @ 4 ohms (< 1.0% THD / 13.8V)
260W x 2 @ 2 ohms (< 1.0% THD / 13.8V)
560W x 1 @ 4 ohms (< 1.0% THD / 13.8V)
2 ohms stable / 4 ohms stable in bridged mode
Full MOS-FET amplification circuitry
Variable subsonic- / lowpass- / bandpass filter,
10/30 – 300Hz with 12/24dB/oct.
Variable input sensitivity: 0.3 – 7V
Damping factor @ 4 ohms: > 350
Signal to noise ratio: > 85dB
Remote low pass level remote control
25mm² direct power input terminals
Dimensions WxHxD: 410 x 62 x 250mm
EA2220
2-CHannel aMplIFIer
270W x 2 @ 4 ohms (< 1.0% THD / 13.8V)
440W x 2 @ 2 ohms (< 1.0% THD / 13.8V)
620W x 2 @ 1 ohm (< 1.0% THD / 13.8V)
870W x 1 @ 4 ohms (< 1.0% THD / 13.8V)
1200W x 1 @ 2 ohms (< 1.0% THD / 13.8V)
1 ohm stable / 2 ohms stable in bridged mode
Full MOS-FET amplification circuitry
Variable subsonic- / lowpass- / bandpass filter,
10/30 – 300Hz with 12/24dB/oct.
Variable input sensitivity: 0.3 – 7V
Damping factor @ 4 ohms: > 350
Signal to noise ratio: > 85dB
Remote low pass level remote control
50mm² direct power input terminals
Dimensions WxHxD: 570 x 62 x 250mm

Downloaded from www.Manualslib.com manuals search engine
2-Kanal verstärKer
150W x 2 @ 4 Ohm (< 1.0% THD / 13.8V)
260W x 2 @ 2 Ohm (< 1.0% THD / 13.8V)
560W x 1 @ 4 Ohm (< 1.0% THD / 13.8V)
2 Ohm stabil / 4 Ohm stabil gebrückt
Full-MOS-FET Verstärkerschaltung
Variables Subsonic- / Tiefpass- / Bandpassfilter,
10/30 – 300Hz mit 12/24dB/Okt.
Variable Eingangsempfindlichkeit von 0.3 – 7V
Dämpfungsfaktor an 4 Ohm: > 350
Signal-Rauschabstand: > 85dB
Externe Basspegel-Fernbedienung
25mm² Strom-Anschluss Terminals
Dimensionen BxHxT: 410 x 62 x 250mm
2-Kanal verstärKer
270W x 2 @ 4 Ohm (< 1.0% THD / 13.8V)
440W x 2 @ 2 Ohm (< 1.0% THD / 13.8V)
620W x 2 @ 1 Ohm (< 1.0% THD / 13.8V)
870W x 1 @ 4 Ohm (< 1.0% THD / 13.8V)
1200W x 1 @ 2 Ohm (< 1.0% THD / 13.8V)
1 Ohm stabil / 2 Ohm stabil gebrückt
Full-MOS-FET Verstärkerschaltung
Variables Subsonic / Tiefpass- / Bandpassfilter,
10/30 - 300Hz mit 12/24dB/Okt.
Variable Eingangsempfindlichkeit von 0.3 – 7V
Dämpfungsfaktor an 4 Ohm: > 350
Signal-Rauschabstand: > 85dB
Externe Basspegel-Fernbedienung
50mm² Strom-Anschluss Terminals
Dimensionen BxHxT: 570 x 62 x 250mm
