EMPHASER EA2160 Einbau & Bedienungsanleitung Seite 33

EA480
4-CHannel aMplIFIer
92W x 4 @ 4 ohms (< 1.0% THD / 13.8V)
145W x 4 @ 2 ohms (< 1.0% THD / 13.8V)
280W x 2 @ 4 ohms (< 1.0% THD / 13.8V)
2 ohms stable / 4 ohms stable in bridged mode
Full MOS-FET amplification circuitry
Variable highpass- / lowpass- / bandpass filter,
10/30 – 300Hz with 12/24dB/oct.
Variable input sensitivity: 0.3 – 7V
Damping factor @ 4 ohms: > 350
Signal to noise ratio: > 85dB
25mm² direct power input terminals
Dimensions WxHxD: 410 x 62 x 250mm
EA450-300
5-CHannel aMplIFIer
60W x 4 & 275W x 1 @ 4 ohms (< 1.0% THD / 13.8V)
85W x 4 & 320W x 1 @ 2 ohms (< 1.0% THD / 13.8V)
180W x 2 & 275W x 1 @ 4 ohms (< 1.0% THD / 13.8V)
2 ohms stable / 4 ohms stable in bridged mode
Full MOS-FET amplification circuitry
Variable highpass- / lowpass- / bandpass filter, 10/30 – 300Hz with 12/24dB/oct.
Variable subsonic highpass filter for CH5, 10 – 60Hz with 12dB/oct.
Variable input sensitivity: 0.3 – 7V
Damping factor @ 4 ohms: > 350
Signal to noise ratio: > 85dB
Remote low pass level remote control
25mm² direct power input terminals
Dimensions WxHxD: 460 x 62 x 250mm
5-Kanal verstärKer
60W x 4 & 275W x 1 @ 4 Ohm (< 1.0% THD / 13.8V)
85W x 4 & 320W x 1 @ 2 Ohm (< 1.0% THD / 13.8V)
180W x 2 & 275W x 1 @ 4 Ohm (< 1.0% THD / 13.8V)
2 Ohm stabil / 4 Ohm stabil gebrückt
Full-MOS-FET Verstärker
Variables Hochpass- / Tiefpass- / Bandpasspassfilter, 10/30 – 300Hz mit 12/24dB/Okt.
Variables Subsonic Hochpassfilter für CH5, 10 bis 60 Hz mit 12dB/Okt.
Variable Eingangsempfindlichkeit von 0.3 – 7V
Dämpfungsfaktor an 4 Ohm: > 350
Signal-Rauschabstand: > 85dB
Externe Basspegel-Fernbedienung
25mm² Strom-Anschluss Terminals
Dimensionen BxHxT: 460 x 62 x 250mm
Downloaded from www.Manualslib.com manuals search engine
4-Kanal verstärKer
92W x 4 @ 4 Ohm (< 1.0% THD / 13.8V)
145W x 4 @ 2 Ohm (< 1.0% THD / 13.8V)
280W x 2 @ 4 Ohm (< 1.0% THD / 13.8V)
2 Ohm stabil / 4 Ohm stabil gebrückt
Full-MOS-FET Verstärkerschaltung
Variables Hochpass- / Tiefpass- / Bandpassfilter,
10/30 – 300Hz mit 12/24dB/Okt.
Variable Eingangsempfindlichkeit von 0.3–7V
Dämpfungsfaktor an 4 Ohm: > 350
Signal-Rauschabstand: > 85dB
25mm² Strom-Anschluss Terminals
Dimensionen BxHxT: 410 x 62 x 250mm
