6.4

Menu overview

1. Measure Config
1.1 Memory Location
1.2 Strike Direction
1.3 Threshold Values
1.4 Average Time
1.5 Material Type
1.6 Hardness Scale
1.7 Probe Option
6.5

Settings

Switch on the device by pressing the On/Off key
In order to enter the menu, press the Menu key
three menu items.
You can select one of the three menu items by using the arrow keys
Confirm your selection by pressing the Menu key
In order to return to measurement mode, press the Back key
confirm any changes made.
1. Measuring configuration
1.1 Memory Location
Here you can determine what file no. the measured values will be saved under. 5 memory
locations are available.
Use the arrow keys
To return, press the Back key
1.2 Strike Direction
Note: You can also select the measuring direction directly via the Direction key
switching on the device.
2. Gauge Config
2.1 Buzzer
2.2 Backlight
2.3 Language Set
2.4 Software Ver
and to select a number between 0 and 5.
. This key is also used to and confirm any changes made.
The arrows in the display show the impact
direction of the impact body. (DIR)
Possible measuring directions:
down (– 90°)
down left or down right (– 45°)
left or right (0°)
up left or up right (45°)
up (90°)
automatic (Indication: DIRC auto)
© PCE Instruments
28
3. Data
3.1 USB
3.2 File No.
3.3 File List
3.4 Delete Data
. You are now in measurement mode.
. In the menu, you will see the icons of the
and
again.
. This key is also used to and
.
when
