No. Description
1 CPU Fan Connector (CPU_FAN2)
2 Power Fan Connector (PWR_FAN1)
3 CPU Fan Connector (CPU_FAN1)
4 ATX 12V Power Connector (ATX12V1)
5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6 ATX Power Connector (ATXPWR1)
7 USB 3.0 Header (USB3_2_3)
8 SATA3 Connector (SATA3_0)
9 SATA3 Connector (SATA3_1)
10 SATA2 Connector (SATA2_5)
11 SATA2 Connector (SATA2_4)
12 Power LED Header (PLED1)
13 Chassis Speaker Header (SPEAKER1)
14 System Panel Header (PANEL1)
15 Chassis Fan Connector (CHA_FAN2)
16 Chassis Fan Connector (CHA_FAN1)
17 USB 2.0 Header (USB6_7)
18 USB 2.0 Header (USB4_5)
19 TPM Header (TPMS1)
20 Infrared Module Header (IR1)
21 Front Panel Audio Header (HD_AUDIO1)
22 SPDIF Out Connector (SPDIF_OUT)
23 Clear CMOS Jumper (CLRCMOS1)
