Serial ATA2 Connectors
(SATA2_4:
see p.1, No. 11)
(SATA2_5:
see p.1, No. 10)
Serial ATA3 Connectors
(SATA3_0:
see p.1, No. 8)
(SATA3_1:
see p.1, No. 9)
USB 2.0 Headers
(9-pin USB4_5)
(see p.1, No. 18)
(9-pin USB6_7)
(see p.1, No. 17)
USB 3.0 Header
(19-pin USB3_2_3)
(see p.1, No. 7)
Front Panel Audio Header
(9-pin HD_AUDIO1)
(see p.1, No. 21)
Downloaded from www.Manualslib.com
1
IntA_PA_SSRX-
IntA_PA_SSRX+
IntA_PA_SSTX-
IntA_PA_SSTX+
IntA_PA_D-
IntA_PA_D+
1
manuals search engine
These two SATA2
connectors support SATA
data cables for internal
storage devices with up to
3.0 Gb/s data transfer rate.
These two SATA3
connectors support SATA
data cables for internal
storage devices with up to
6.0 Gb/s data transfer rate.
Besides four USB 2.0 ports
USB_PWR
on the I/O panel, there
P-
P+
GND
are two headers on this
DUMMY
motherboard. Each USB
2.0 header can support
GND
P+
P-
two ports.
USB_PWR
Besides two USB 3.0 ports
Vbus Vbus
Vbus IntA_PB_SSRX-
on the I/O panel, there
IntA_PB_SSRX+
GND
is one header on this
GND IntA_PB_SSTX-
IntA_PB_SSTX+
motherboard. Each USB
GND
GND IntA_PB_D-
3.0 header can support
IntA_PB_D+
Dummy
two ports.
1
This header is for
GND
PRESENCE#
connecting audio devices
MIC_RET
OUT_RET
to the front audio panel.
OUT2_L
J_SENSE
OUT2_R
MIC2_R
MIC2_L
P81 Pro3
