2) VENTILATION SYSTEM

1
2
1.3) Customised visor opening
For the AX-8 Dual it is possible to replace the tooth mechanism
and customise the visor opening. The 2 mechanisms available
have different numbers of different thickness teeth, depending
on the type of use.
- Red mechanism (fitted as standard): visor lock in open or
closed position and intermediate visor lock positions.
- Blue mechanism: visor lock in fully open or fully closed po-
sition without intermediate positions.
To remove the tooth mechanism, pull it outwards (1). To rein-
stall or replace it, position it in its housing and push the me-
chanism (2) until it clicks into place.
Top air inlet
Front air inlets
Air inlets incorporated into the
edge of the visor
Channels through polystyrene
Muzzle air inlet
Side air extractors
Upper air extractors
Lower air extractors
