13
TECHNISCHE DATEN
13.2.2.2

Modulstatus

Tabelle 28: Modulstatusbits Hauptmodul
Bit 7
Byte 0
Reserviert
Byte 1 ... 3
Reserviert
Byte 4
Benutzerde‐
finiertes
Status-Bit 7
(CPU-Logik)
32
B E T R I E B S A N L E I T U N G | Flexi Gateway GETC1
Tabelle 26: Service-Daten-Objekt 0x4000 - Prüfsummen
Index
Subindex
0x4000
00
01
02
03
04
05
Überblick
In den ersten 32 Bytes stehen die Modulstatus der CPU. Anschließend folgen dann in je
8 Bytes die Modulstatus der Erweiterungsmodule. Die Reihenfolge ist abhängig von der
Hardwarekonfiguration. Der Inhalt ist abhängig von der Art der Erweiterungsmodule.
Modulstatus
Tabelle 27: Service-Daten-Objekt 0x4001 Modulstatus
Index
Subindex
0x4001
00
0x4001
01
0x4001
02
0x4001
03
0x4001
04
0x4001
05
0x4001
06
...
0x4001
16
Modulstatusbits Hauptmodul
Bit 6
Bit 5
Bit 4
Spannungs‐
Konfigura‐
versorgung
tion gültig
Benutzerde‐
Benutzerde‐
Benutzerde‐
finiertes
finiertes
finiertes
Status-Bit 6
Status-Bit 5
Status-Bit 4
(CPU-Logik)
(CPU-Logik)
(CPU-Logik)
Inhalt
Anzahl der Einträge = 5
Gesamtprüfsumme
Sicherheitsprüfsumme
Standardprüfsumme
Reserviert
Verifizierungsprüfsumme
Inhalt
Anzahl der Einträge = 16
CPU-Status-Info Teil 1 von 4
CPU-Status-Info Teil 2 von 4
CPU-Status-Info Teil 3 von 4
CPU-Status-Info Teil 4 von 4
Modul-Status-Info 1
Modul-Status-Info 2
Modul-Status-Info 12
Bit 3
Bit 2
Reserviert
Externer
Fehler
Benutzerde‐
Benutzerde‐
finiertes
finiertes
Status-Bit 3
Status-Bit 2
(CPU-Logik)
(CPU-Logik)
Datentyp
Größe
USINT
1 Byte
BYTE
4 Bytes
BYTE
4 Bytes
BYTE
4 Bytes
BYTE
4 Bytes
BYTE
4 Bytes
Datentyp
Größe
USINT
1 Byte
ARRAY of
8 Bytes
BYTE
ARRAY of
8 Bytes
BYTE
ARRAY of
8 Bytes
BYTE
ARRAY of
8 Bytes
BYTE
ARRAY of
8 Bytes
BYTE
ARRAY of
8 Bytes
BYTE
ARRAY of
8 Bytes
BYTE
Bit 1
Bit 0
Interner
Betriebszu‐
Fehler
stand
1 = Run
0 = Anderer
Benutzerde‐
Benutzerde‐
finiertes
finiertes
Status-Bit 1
Status-Bit 0
(CPU-Logik)
(CPU-Logik)
8024578/2020-11-10 | SICK
Irrtümer und Änderungen vorbehalten
