PG-Switch / AG-Switch

11 Technical Data

Supply voltage
Input
Powerinput 24Vinput for
switching (only PG-Switch
II / AG-Switch II)
Functional control
Working temperature
Dimensions

12 Troubleshooting

Faults:
LED on Switch is dark
No communication to all PLC´s
The PG operates with troubles
The sensor-port of the PG-Switch III
doesn´t works
22
+5VDC +/- 5% (taken out of the 1.PLC (AG1))
ca. 1.1 VA
15mA
A LED for the aktivated port
5 to 55 degree Celsius
metal casing 135 x 110 x 50 mm
Possible Cause:
· Check the connection-cable to the 1.PLC (AG1)
· +5VDC on the PG-port of the 1. PLC (AG1)
correct?
· Needs the connected PG or PC a power supply or a
20mA current source who doesn´t offers the
connected 1. PLC (AG1)
· Is the earth-cable connected?
· Are some unspecificated cables connected?
· Needs the connected PG or PC a power supply who
doesn´t offers the connected 1. PLC (AG1)
· PG´s/PC´s who needs some 0mA current sources,
are not working at this Switch (see also the captures
before)
