8.4 AG-SWITCH I

· Connecting of two PLC´s at at one PLC
· The PLC1 and the PLC are switchable with a two-position switch at the metal casing. A
LED shows the aktive switch-port
· No external powersupply is need for the work of the internal electronic of the PG-Switch.
The electronic takes the power out of the „AG"-PLC (only the 5VDC)
· Can be operated by all original and compatible programming devices
· Aktive PG-ports (the 20mA were switched from the connected PLC at the AG1-port to the
PG-port)
· Active PLC-ports. All PLC´s can be connected with a 15pin 1:1 cable to the AG-Switch
· All components were connectable as usual without any adaptors.
· All connections and operating elements are at the front of the device
· Compact device in a metal casing

8.5 AG-SWITCH II

· Connecting of two PLC´s at at one PG
· The PLC´s are switchable with a 24VDC input on the metal case (for example switchable
from a outputport of the PLC).
24VDC off = AG1 active
24VDC on = AG2 active
A LED shows the aktive switch-port
· No external powersupply is need for the work of the internal electronic of the AG-Switch.
The electronic takes the power out of the „AG1"-PLC (only the 5VDC)
· Can be operated by all original and compatible programming devices
· Aktiv PG-ports (the 20mA were switched from the connected PLC to the choosed PG-port)
· Active PLC-ports. All PLC´s can be connected with a 15pin 1:1 cable to the AG-Switch
· All components were connectable as usual without any adaptors.
· All connections and operating elements are at the front of the device
· Compact device in a metal casing
