9 Connector assignment PG-Switch I / II / III
AG Interface
This Interface should be 1:1 connected with the Siemens-PLC, for a correct work of the PG-
Switch. The pins below this text are inputs of the PG-Switch.
The PG-Switch have internally connected aktive receiver and transmitter. The pins 2, 9, 6, 7
must be connected 1:1 with the PLC.
PIN
Notation Signalname
1
MEXT
Internal ground
3
5VDCin
Currend supply +5V DC
4
24VDCin Current supply +24V DC
5
Ground
Internal ground
8
MEXT
External ground
10
Ground
Ground for 24V
11
I-Tx in
I-IN
12
Ground
Internal ground
13
I-Rx in
I-IN
14
5VDCin
Current supply +5V DC
15
Ground
Internal ground
PG1/PG2-Interface
This pining is the same pining of the PG-Interface on a Siemens S5
PIN
Notation.
1
GEXT
2
TTY IN-
3
+5V
4
+24V
5
Ground
6
TTY OUT+
7
TTY OUT-
8
GEXT
9
TTY IN+
10
Ground
11
I-Tx
12
Ground
13
I-Rx
14
+5V
15
Ground
* not connected at the PG-Switch III at the PG1-port.
ÓCopyright by PI
Signalname
External ground
Receiver minus
Current supply +5V DC
Current supply +24V DC
Internal ground
Transmitter plus
Transmitter minus
External ground
Receiver plus
Ground for 24V
20mA current source
Internal ground
20mA current source
Current supply +5V DC
Internal ground
*
*
PG-Switch / AG-Switch
