PG-Switch / AG-Switch

8.6 AG-SWITCH I 4-fach

· Connecting of four PLC´s at at one PLC
· The PLC1 - PLC4 are switchable with a two-position switch at the metal casing. A LED
shows the aktive switch-port
· No external powersupply is need for the work of the internal electronic of the AG-Switch.
The electronic takes the power out of the „AG1"-PLC (only the 5VDC)
· Can be operated by all original and compatible programming devices
· Aktive PG-ports (the 20mA were switched from the connected PLC at the AG1-port to the
PG-port)
· active PLC-ports. All PLC´s can be connected with a 15pin 1:1 cable to the AG-Switch
·
· All components were connectable as usual without any adaptors.
· All connections and operating elements are at the front of the device
· Compact device in a metal casing
· Easy mounting into the switchboard
