8 FEATURES

8.1 PG-SWITCH I

· Connecting of two PG´s at at one PLC
· The PG are switchable with a two-position switch at the metal casing. A LED shows the
aktive switch-port
· No external powersupply is need for the work of the internal electronic of the PG-Switch.
The electronic takes the power out of the „AG"-PLC (only the 5VDC)
· Can be operated by all original and compatible programming devices
· Aktiv PG-ports (the 20mA were switched from the connected PLC to the choosed PG-port)
All components were connectable as usual without any adaptors.
· All connections and operating elements are at the front of the device
· Compact device in a metal casing

8.2 PG-SWITCH II

· Connecting of two PG´s at at one PLC
· The PG are switchable with a 24VDC input on the metal case (for example switchable
from a outputport of the PLC).
24VDC off = PG1 active
24VDC on = PG2 active
A LED shows the aktive switch-port
· No external powersupply is need for the work of the internal electronic of the PG-Switch.
The electronic takes the power out of the „AG"-PLC (only the 5VDC)
· Can be operated by all original and compatible programming devices
· Aktiv PG-ports (the 20mA were switched from the connected PLC to the choosed PG-
port). All components were connectable as usual without any adaptors.
· All connections and operating elements are at the front of the device
· Compact device in a metal casing
