PG-Switch / AG-Switch
10 Connector assignment AG-Switch I / II / I 4-fach
AG Interface
This Interface should be 1:1 connected with the Siemens-PLC, for a correct work of the AG-
Switch. The pins below this text are inputs of the PG-Switch. The power supplys and the
20mA current sources were only taken from the PLC1 (AG1)-port.
The AG-Switch have internally connected aktive receiver and transmitter. The pins 2, 9, 6, 7
must be connected 1:1 with the PLC.
PLC1/PLC2/PLC3 /PLC4
*
PIN Notation Signalname
1 MEXT Internal ground
3 5VDCin Currend supply +5V DC
4 24VDCin Current supply +24V DC
5 Ground Internal ground
8 MEXT External ground
10 Ground Ground for 24V
11 I-Tx in 20mA current source IN
12 Ground Internal ground
13 I-Rx in 20mA current source IN
14 5VDCin Current supply +5V DC
15 Ground Internal ground
*PLC3/PLC4-port only at the AG-Switch I 4-fach
** This pins are only need on the PLC1-port
20
-port
*
**
**
**
**
**
**
