Proper use

The machine is designed for mixing liquid and powder-
based building products such as paints, mortar,
adhesives, plaster and similar substances. Use the right
mixing tool for the consistency of the material and the
when choosing the size of mixing tool (diameter/
diameter is selected, this may cause the machine/gear
unit to become overloaded and lead to damage as a
result. Please remember that a mixing tool with a mixing
Given the high torque levels generated by the machine, it
must not be used as a power drill.
The machine is not suitable for mixing materials
containing graphite dust, brine or slurry. Mixing of
these materials or substances may damage the machine
beyond repair.
Assembly
with the packaging and screw it to the male thread of the
HEXAFIX (Fig. A)
mixing tools, simply pull back the handle-collar
on the coupling and this releases the mixing tool.
(Fig. C)
M-14 (Fig. B)
Screw the mixing tool with a size M14 male thread into
To release the mixing tool you will need one SW 22
and one SW 24 open-ended wrench. Place the one
open-ended wrench on the adapter and the other on
is released.
plate is the same as the mains power supply.
Always hold the machine with both hands.
1.
(1).
Press the ON/OFF switch (2).
The more pressure you apply to
the ON/OFF switch,
the faster the machine will run.
2.
The ON/OFF switch cannot be
locked!
Always work with the ON/OFF switch fully pressed.
To stop working, release the ON/OFF switch.
Machines with 2-speed gear units (Xo4R/Xo6R) have two
maximum speeds available (First gear: Slow / Second
gear: Fast).
To change from one gear to the
lever through 180°.
Only ever actuate it when the
Always reduce the speed when submerging the mixing
mixing tool is fully submerged, increase the speed again
to ensure that the motor is adequately cooled.
During mixing you should guide the machine around
mixing material is completely mixed. Please follow the
material.
The greater the viscosity of the material, the greater
the impact of the torque forces on the machine, so you
should be prepared for this when you carry out your
work.
If the mixing tool comes into contact with a surface (e.g.
be inserted through the hexagon punch-hole provided in
the handle frame.
