EN
16

FUNCTION KEYS

Control panel

INSTALLATION

Wall installation

The unit must be installed at least 15 cm above the floor and at a minimum distance of
50 cm from the ceiling. Four fixed retaining screws (M8) are located at the rear of the
unit body.
The following accessories are included in the delivery:
1 Control panel
2 On/off button
3 Parental control
4 Timer button
5 Mode button
6 Raise temperature
7 Reduce temperature
8 Mounting bracket
9 Wall spacer
10 Washer
1 1 Fastening nut
12 Dowels
13 Screw 4*35 mm
