Rear View
(9)
Antenna connection (TNC)
(10) Unbalanced audio output (left channel)
(11) Unbalanced audio output (right channel)
(12) Audio input (left channel). Combo socket for balanced and unbalanced signal inputs
(13) Audio input (right channel). Combo socket for balanced and unbalanced signal inputs
(14) DC connection for 15 VDC power supply unit
1.3
How to install the Transmitter
•
Place the transmitter in the same room or area as the receiver.
•
Always try to ensure a line of path between the transmitter and receiver; obstacles such
as walls can significantly reduce the radio signal strength.
•
Avoid using the IMS 900 system near digitally controlled devices, computers or mobile
telephone equipment.
1.4
Setting up
1.4.1 How to connect the Antenna
Connect the antenna to the antenna connection (9).
27
