Function

Actuators control connected loads in accordance with
the wireless commands they receive. Commands are
transmitted by actuating buttons or remote controls,
or via a software interface. It is also possible to
control actuators via taught-in sensors. When an
event occurs, the sensors transmit a command (in the
same way as a button). Refer to the manual for the
corresponding sensor for more detailed information.
C
B A
A Channel buttons
B Connecting terminals for the load to be controlled
C Supply voltage terminals
