3-5. Mounting dimensions

PL25 / SL110
PL25 / SL130
PL60 / SL331
Recommended
Clearance
PL25 / SL110
0.8
PL25 / SL130
PL60 / SL331 0.5
63
35
Head
29.5
4.5
51.5 Effective length
63
35
Head 29.5
4.5
50 Effective length
Unit: mm
Mounting
35
hole for M4 ×
20 screw
12
‒0.5 +0.5
12
Mounting
hole for M4 ×
20 screw
‒2 +2
10
13
