WARNING
• If the battery pack or charger is damaged, replace the
battery pack or the charger.
• Stop the machine and wait until the motor stops before
you install or remove the battery pack.
• Read, know, and do the instructions in the battery and
charger manual.
1. Align the lift ribs on the battery pack with the grooves in
the battery compartment.
2. Push the battery pack into the battery compartment until
the battery pack locks into place.
3. When you hear a click, the battery pack is installed.
3.5

REMOVE THE BATTERY PACK

Figure 4.
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
4

OPERATION

IMPORTANT
Before you operate the machine, read and understand the
safety regulations and the operation instructions.
WARNING
Be careful when you operate the machine.
4.1

START THE MACHINE

Figure 5.
1. Pull back on the lock-out button and pull the trigger.
4.2

STOP THE MACHINE

Figure 5.
1. Release the trigger to stop the machine.
4.3

OPERATION TIPS

Figure 6.
WARNING
Keep clearance between the body and the machine.
WARNING
Do not operate the machine without guard in place.
Do these tips when you use the machine
• Keep the machine connected to the correctly worn
harness.
• Keep a firm hold with the two hands on the machine
while you operate the machine.
English
• Cut tall grass from the top down.
If grass winds around the trimmer head:
• Remove the battery pack.
• Remove the grass.
4.4

CUTTING TIPS

Figure 7.
• Tilt the machine toward the area to be cut. Use the tip of
the cutting line to cut grass.
• Move the machine from right to left to prevent thrown
debris toward the operator.
• Do not cut in the dangerous area.
• Do not force the trimmer head into uncut grass.
• Wire and picket fences cause cutting line wear and
breakage. Stone and brick walls, curbs, and wood can
wear the cutting line quickly.
4.5 ADJUST THE LENGTH OF THE
CUTTING LINE MANUALLY
Figure 8
1. Stop the machine.
2. Push the spool retainer button and pull on cutting line to
manually advance the cutting line.
3. After you extend new cutter line, always return the
machine to its normal position before you start it again.
4.6

LINE CUT-OFF BLADE

Figure 9.
This trimmer is equipped with a line cut-off blade on the
guard. The line cut off blade continuously trims the line to
ensure a consistent and efficient cut diameter. Advance line
whenever you hear the engine running faster than normal, or
when trimming efficiency diminishes. This will maintain best
performance and keep line long enough to advance properly.
4.7 ADJUST THE LENGTH OF THE
CUTTING LINE
Figure 5.
The machine has an auto-feed head. It will damage the
machine if you hit the head to try to advance the line.
If the cutting line does not automatically advance, it can be
tangled or empty.
1. When the machine is on, release the trigger.
2. Wait two seconds, push the trigger again.
5
