The camera uses a 3.7 volts rechargeable Li-ion Battery.
1. Press the Battery Door Latch that is located at the upper side of the unit to open the back cover.
2. Slide the battery into the battery compartment and align with the metal contact.
3. Replace the back cover.
2
Charging by AC-Adapter
1. Plug the AC end of the adaptor into a standard AC socket.
2. Plug the USB end of the adaptor into the USB port of the
camera. The red backlight will be turned on.
• Charging the battery for the first time will takes about 6
hours. When the battery is fully charged, the red
backlight will go off.
• Charging the battery fully for the second time or later will
take at least 2 hours.
• When charging the battery for the first time, it is
recommended to use AC adaptor instead of USB cable.
Charging by PC / Notebook
You can also use the USB cable to charge the battery.
1. Connect the bigger end of the USB cable to the USB port of your PC
or Notebook.
2. Plug the smaller end of the USB cable to the USB port of the camera.
• The red backlight will turn on when the battery is being charged
and it will turn off when the unit is fully charged. The time for fully
charging is about 4-6 hours.
3
The camera uses SD or MMC card as storage. Insert an SD or MMC
card according to the illustrations below before proceeding to take video
clips or pictures.
To remove the memory card, gently push the edge of the memory card
with your fingertip to eject it first, and then pull the card out.
DZ QSG(515815-00)-E
Downloaded from www.Manualslib.com

LOADING THE BATTERY

CHARGING THE BATTERY

INSTALLING THE MEMORY CARD

2
manuals search engine
AC end
2
USB end
