ATTACHING THE WRIST STRAP

Please attach the supplied strap to prevent dropping the camera.

LOADING THE BATTERIES

fig.1.1
The camera uses 2x AA batteries.
1. Slide the Battery/Memory Card Door towards the center of the camera, and lift the
Battery/Memory Card Door to open. (fig. 1.1)
2. Insert the batteries with the positive terminal toward the ( + ) sign, and the negative
terminal toward the ( – ) sign. (fig. 1.2)
3. Close the battery/memory card door. (fig. 1.3)

INSERTING MEMORY CARD

In addition to having a 7MB internal memory, the camera can use MultiMediaCard (MMC) or
Secure Digital (SD) memory cards to store images and video clips.
1. Slide the Battery/Memory Card Door towards the center of the
camera and lift the Battery/Memory Card Door to open. (fig.1.1)
2. Insert the memory card into memory card slot with its metal contacts
exposed side down and its printed side facing outward. (fig.1.4)
3. Close the battery/memory card door. (fig.1.3)
Downloaded from www.Manualslib.com
1
manuals search engine
A
AWB
005/042
2
fig.1.2
2
GETTING STARTED
3
fig.1.3
fig.1.4
