OPERATION
Set-up the laser on a flat and even surface or mount it onto a tripod.
Press the ON/OFF button (1) to power on the laser.
After POWER ON the laser automatically self-levels. The laser beam and the TILT LED (4) flash indica-
ting that the automatic self-levelling procedure is activated. This self-levelling procedure may take up
to 90 sec. When completed the TILT LED (4) is illuminated. The laser starts rotating at 800 rpm. If the
TILT LED (4) continues to flash and the alarm beep sounds the laser was most likely set up outside its
self-levelling range of ± 5°. Re-position the instrument on more even surface.
VERTICAL USE
·
Unfold the datum point on the integrated floor mount and set up the laser in its vertical (lay-down)
position.
·
The laser automatically self-levels in this position.
·
Set the ciruclar bubble as accurately as possible by using the two thumb screws. This ensures that
the instrument is set within its self-levelling range and the rotating beam is centered over its datum
point.
Downloaded from
www.Manualslib.com
Datum
point
manuals search engine
Foot screw
EN
E
39
