3.1 Standard mounting brackets
The MARK Infra ER electric radiant panel comes with a pair of standard mounting brackets. These
adjustable brackets allow direct ceiling or wall mount, and come with preset angle options.
Step 1: Assemble the adjusting bracket to a
sliding bracket.
Step 3: Fix adjusting bracket into the wall by
expansion screws.
6 6
Step 2: Installation of sliding bracket & heater
as pointed by arrow.
Step 4: Installation of two adjusting brackets,
make sure brackets are locked tight with
screws
