setting all parameters to default factory settings.
Factory settings for all programs
(The following settings are set after 3 sec. reset via
from USER MENU)
STATUS:
Wire Inch FORWARD speed:
PULSE MODE
WIRE Speed:
START Delay:
STOP Delay:
Retract SPEED:
Retract TIME:
Main speed pulse TIME
Second speed pulse TIME:
Second speed:
Error codes
When using the CWF, the following errors can be
displayed on the unit:
Motor overload
Peak current on motor exceeds the limit
Problems on tachometric control of speed
Duplicate Id. More than one CWF with the
same Id is connected to PI. Change the Id of
one unit.

Technical data

Wire feed speed
Wire diameter
Dimensions (HxWxL)
Weight
Downloaded from www.Manualslib.com
CLEAR
Used to cancel in one step all programs by
OFF
1.0 m/min
Disabled
1.0 m/min
0 sec.
0 sec.
0.5 m/min
0 sec.
0.5 m/min
0.5 m/min
0 m/min
0.2 – 5 m/min
0.6 – 2.4 mm
27.6x21.1x27.6 cm
9.6 kg
