VITROCERAMIC HOBS
Fig. 1.1
SCHOTT
2
1
10
12 11
8
Fig. 1.4
SCHOTT
5
3
8 10
12 11
COOKING POINTS
1. 3 circuits cooking zone Ø 145 - 1200 W
2. 3 circuits cooking zone Ø 180 - 1700 W
3. Hi-light cooking zone Ø 145 - 1200 W
4. Hi-light cooking zone Ø 180 - 1800 W
5. Halogen cooking zone Ø 180 - 1800 W
6. Haloring cooking zone Ø 145 - 1200 W
7. Haloring cooking zone Ø 180 - 1800 W
FEATURES
- Overheating surfaces protection Type Y.
Fig. 1.2
10
8
9
Fig. 1.5
SCHOTT
9
10 12 11
8
- Electrical isulation Class I.
SCHOTT
4
3
12
11
9
5
6
9
CONTROL PANEL DESCRIPTION
8. Front zone control knob
9. Rear zone control knob
10. Front zone residual heat indicator
11. Rear zone residual heat indicator
12. Power indicator light
Fig. 1.3
SCHOTT
5
1
10
12 11
8
Fig. 1.6
SCHOTT
7
6
10 12 11
8
9
9
