Wireless Mode

Many models of the GRAFIK Eye
Lutron products. This feature allows for easy integration of wireless sensors, keypads,
remotes, and window treatments for single-room wireless applications, as well as
compatibility with other Lutron wireless systems.
Units supporting wireless communication have model numbers beginning with QSGRJ,
QSGRK, or QSGRM.
The wireless feature of the GRAFIK Eye QS Wireless control unit has three (3) modes of
operation.
• Disabled: Use for wired-only systems.
• Enabled: The GRAFIK Eye QS Wireless control unit will respond to any programming
commands from nearby Lutron QS wireless (and compatible) products.
• Ignore Programming (default): The GRAFIK Eye QS Wireless control unit will only
respond to normal operation commands from wireless devices programmed while in
Enabled mode.
To change the wireless mode of the GRAFIK Eye QS wireless control unit:
1. Enter programming mode (see page 9).
Main menu
2. Use the Master buttons to highlight "Wireless Mode" and press
Shade labels
3. Use the Master buttons to highlight the desired wireless mode,
Wireless Mode
4. The info screen will display a confirming "Saved" message.
Wireless Mode
5. Exit programming mode (see page 9).
Enabled
• The wireless signal has a range of 10 m (30 feet) through
Saved
Saved
Downloaded from www.Manualslib.com
QS support wireless communication with other
®
the OK button to accept.
and press the OK button to accept.
Notes
standard construction.
For additional information, see the complete installation and operation guide at www.lutron.com/qs
®
manuals search engine
1 9 2 10 3 11 4 12 5 13 6
GRAFIK Eye QS with DALI Quick Installation and Operation Guide 10
®
14 7 15 8 16
9-16
1-8
OK
Master
buttons
OK
button
Timeclock
(back) button
