Wiring the GRAFIK Eye

Overview of PELV (Class 2: USA) Wiring

IR Wiring
1,0 mm
(18 AWG)
2
each terminal
From external
IR connection
(by others)
Contact Closure Input Wiring
For settings, see complete installation and
operation guide at www.lutron.com/qs.
Example:
Occupancy sensor
(maximum 1)
Downloaded from
www.Manualslib.com
QS with DALI:
®
1: IR DATA
2: IR COM
A: CCI SIG
B: 24 V
C: CCI COM
Control Wiring
Common and power (terminals 1 and 2):
Two 1,0 mm
1,0 mm
(18 AWG)
2
each terminal
For additional information, see the complete installation and operation guide at www.lutron.com/qs
®
manuals search engine
(18 AWG) each terminal
2
To control stations,
window treatments,
or other GRAFIK Eye
QS control units
Data (terminals 3 and 4):
Twisted, shielded pair 0,5 mm
each terminal
GRAFIK Eye
QS with DALI Quick Installation and Operation Guide 6
®
1 2 3 4 5 6 L N
1 2 3 4 5 6 L N
1: COM
2: 24 V
*
* Do not connect terminal 2
3: MUX
between any GRAFIK Eye QS
4: MUX
and any other power supply,
including another GRAFIK Eye
QS. See complete installation
and operation guide at www.
(22 AWG)
lutron.com/qs. for detailed wiring
2
example.
Note: Use appropriate wire connecting devices
as specified by local codes.
N H 1 2 3
