DALI Setup

Assign/Unassign a DALI Device to a Zone (Zone setup)
DALI devices must be addressed on the system (see previous page) before assigning
or unassigning to a zone.
1. Enter programming mode (see page 9).
Main menu
2. Use the Master buttons to highlight "DALI" and press the OK
Zone setup
Zone setup
3. Use the Master buttons to highlight "Assign zones" and press
DALI
4. Use the Master buttons to scroll through the DALI devices on
DALI
Assign zones
Address All
Assign zones
Ballast 2 / 23
*Unassigned*
5. Press the timeclock (back) button to return to the DALI menu.
Assign zones
6. Exit programming mode (see page 9).
Ballast 2 / 23
Zone 3
Downloaded from www.Manualslib.com
button to accept.
the OK button to accept.
the link. The selected device will flash, and the info screen
will display the device number and the number of devices on
the link. If the device is currently assigned to a zone, the zone
number will display at the bottom of the screen and the LEDs
for the zone will go on; otherwise, the info screen will display
"*Unassigned*".
• Press the zone raise button to assign the device to that
zone.
• Press the zone lower button to unassign the device to that
zone.
DALI devices will return to normal levels.
Notes
Devices that were previously assigned to a zone will be
removed from the old zone and assigned to the new zone
(each device can be assigned to only 1 zone at a time).
Devices can be assigned only to zones set to DALI load type.
Refer to page 11 for instructions on changing load type.
For additional information, see the complete installation and operation guide at www.lutron.com/qs
®
manuals search engine
1 9 2 10 3 11 4 12 5 13 6
GRAFIK Eye QS with DALI Quick Installation and Operation Guide 13
®
14 7 15 8 16
9-16
1-8
OK
3
1 9 2 10 11
Zone LEDs
Master
buttons
OK
button
Timeclock
(back) button
4 12 5 13 6 14 7 15 8 16
Use the
zone raise
or lower
button to
assign or
unassign
a DALI
device to
that zone.
